FTTH Mini ONU 1 GE Gigabit Ethernet 1 Pon Port GPON Xpon ONT Fiber Optic Network Unit
FTTH Mini ONU 1 GE Gigabit Ethernet 1 Pon Port GPON Xpon ONT Fiber Optic Network Unit - Image 2
FTTH Mini ONU 1 GE Gigabit Ethernet 1 Pon Port GPON Xpon ONT Fiber Optic Network Unit - Image 3

FTTH Mini ONU 1 GE Gigabit Ethernet 1 Pon Port GPON Xpon ONT Fiber Optic Network Unit

₹800.00

  • 1 GE Gigabit Ethernet ONT 1 Pon Port GPON ONU Xpon Fiber Home HTTH Xgpon ONU

    Product Introduction：

    G55 is a single port GPON SFU, which provides users with uplink optical access, uses optical fiber wiring, signal transmission is not affected by electromagnetic interference, low bit error rate, small delay, high transmission quality, and better reflects broadband performance. The product is small, green, low-power, RoHS compliant, cost-effective and easy to install and maintain. White casing is adopted in appearance, which is simple and bright.

    Product Characteristics：

    • GPON SFU,stable and low latency.
    • Small, green, low-power, RoHS complian.
    • Cost-effective and easy to install and maintai

18 in stock

SKU: 5487FB8/11-1-1 Categories: , , Tags: , , , ,

Description

XPon Mini ONU Interface Function

  • 1 *G/EPON interface：SC/UPC/APC interface，Comply with GPON and EPON standards
  • 1* Ethernet interface：10Mbps/100Mbps/1000Mbps，RJ-45，Comply IEEE802.3–2005 standards
LED PWR+PON/LOS+LAN
Port 1*RJ45(GE)
1*Reset
1*SC/APC (or SC/UPC)
1*DC
Size 79.5*74.7*22mm(L*W*H)
Power Consumption ≤8W
Ethernet Port Ethernet port-based VLAN tags and tag removal
VLAN transparent and aggregation
MAC address learning
10/100/1000Mbps Auto negotiation



Solfware Parameters

G/EPON ITU-T G.984.1-4
IEEE 802.3ah
15 TCONTs /256GEM ports
8 Egress queues per TCONT at least
VLAN or VLAN plus priority gem mapping mode
SN/LOID/SN+ Password authentication
Performance monitoring: eth/Gem port
Dying gasp
Layer 2 Features MAC learning (SVL)/aging
Support max frame length to1518 bytes
VLAN tagging for untagged packets
Support VLAN 1-4094
VLAN transparent/translation
Multicast IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376)
IGMP snooping
Management OMCI/Web UI

Environment

Operate Temperature 0℃~45℃
Storage Temperature -20℃~70℃
Operating Humidity 5%～95% non-condensing
Power Supply 12V/0.5A
